圆形类连接器

SV

Plug acc. to IEC 61076-2-106, IP40, straight version, with threaded joint, solder terminals and bend protection, for cable diameter up to 6 mm

SV ...-8

Plug acc. to IEC 61076-2-106, IP40, straight version, with threaded joint, solder terminals and bend protection, for cable diameter up to 8 mm

新

SV ... C

Plug acc. to IEC 61076-2-106, IP40, straight version, with threaded joint, empty housing for reception of crimp contacts, with bend protection, for cable diameter up to 6 mm

新

SV ...-8 C

Plug acc. to IEC 61076-2-106, IP40, straight version, with threaded joint, empty housing for reception of crimp contacts, with bend protection, for cable diameter up to 8 mm

WSV

Plug acc. to IEC 61076-2-106, IP40, right angle version, with threaded joint, solder terminals and bend protection, for cable diameter up to 6 mm

新

WSV ... C

Plug acc. to IEC 61076-2-106, IP40, angular version, with threaded joint, empty housing for reception of crimp contacts, with bend protection, for cable diameter up to 6 mm

KV

Socket acc. to IEC 61076-2-106, IP40, straight version, with threaded joint, solder terminals and bend protection, for cable diameter up to 6 mm

KV ...-8

Socket acc. to IEC 61076-2-106, IP40, straight version, with threaded joint, solder terminals and bend protection, for cable diameter up to 8 mm

新

KV ... C

Socket acc. to IEC 61076-2-106, IP40, straight version, with threaded joint, empty housing for reception of crimp contacts, with bend protection, for cable diameter up to 6 mm

新

KV ...-8 C

Socket acc. to IEC 61076-2-106, IP40, straight version, with threaded joint, empty housing for reception of crimp contacts, with bend protection, for cable diameter up to 8 mm

WKV

Socket acc. to IEC 61076-2-106, IP40, angular version, with threaded joint, solder terminals and bend protection, for cable diameter up to 6 mm

新

WKV ... C

Socket acc. to IEC 61076-2-106, IP40, angular version, with threaded joint, empty housing for reception of crimp contacts, with bend protection, for cable diameter up to 6 mm

SFV

Chassis plug acc. to IEC 61076-2-106, IP40, with threaded joint and solder terminals, for front mounting

新

SFV ... C

Chassis plug acc. to IEC 61076-2-106, IP40, with threaded joint, empty housing for reception of crimp contacts, for front mounting

SGV

Chassis plug acc. to IEC 61076-2-106, IP40, with threaded joint and solder terminals, for back side mounting

新

SGV ... C

Chassis plug acc. to IEC 61076-2-106, IP40, with threaded joint, empty housing for reception of crimp contacts, for back side mounting

SGR

Chassis plug acc. to IEC 61076-2-106, IP 40, with threaded joint, for printed circuit boards, for back side mounting

KFV

Chassis socket acc. to IEC 61076-2-106, IP40, with threaded joint and solder terminals, for front mounting

新

KFV ... C

Chassis socket acc. to IEC 61076-2-106, IP40, with threaded joint, empty housing for reception of crimp contacts, for front mounting

KGV

Chassis socket acc. to IEC 61076-2-106, IP40, with threaded joint and solder terminals, for back side mounting

新

KGV ... C

Chassis socket acc. to IEC 61076-2-106, IP40, with threaded joint, empty housing for reception of crimp contacts, for back side mounting

KFR

Chassis socket acc. to IEC 61076-2-106, IP40, with threaded joint, for printed circuit boards, for front mounting

KGR

Chassis socket acc. to IEC 61076-2-106, IP40, with threaded joint, for printed circuit boards, for back side mounting

新

030398

Chassis socket acc. to IEC 61076-2-106, IP40, with threaded joint and ground contact, for printed circuit boards, for rear mounting

0331

Plug acc. to IEC 61076-2-106, IP68, with threaded joint and solder terminals

0332

Plug acc. to IEC 61076-2-106, IP68, with threaded joint and solder terminals, shielded at 360°

0332-1

Plug acc. to AISG specification and IEC 61076-2-106, IP68, with threaded joint and solder terminals, shielded at 360°

033200

Plug acc. to AISG specification and IEC 61076-2-106, IP68, with threaded joint, vibration protection and solder terminals, 360° shielded, optimized assembly

0365

Plug acc. to AISG specification and IEC 61076-2-106, IP68, with threaded joint, empty housing for reception of crimp contacts, shielded at 360°

036500

Plug acc. to AISG specification and IEC 61076-2-106, IP68, with threaded joint and vibration protection, empty housing for reception of crimp contacts, 360° shielded, optimized assembly

0321

Socket acc. to IEC 61076-2-106, IP68, with threaded joint and solder terminals

0322

Socket acc. to IEC 61076-2-106, IP68, with threaded joint and solder terminals, 360° shielded

0322-1

Socket acc. to AISG specification and IEC 61076-2-106, IP68, with threaded joint and solder terminals, shielded at 360°

032200

Socket acc. to AISG specification and IEC 61076-2-106, IP68, with threaded joint, vibration protection and solder terminals, 360° shielded, optimized assembly

0360

Socket acc. to AISG specification and IEC 61076-2-106, IP68, with threaded joint, empty housing for reception of crimp contacts, shielded at 360°

036000

Socket acc. to AISG specification and IEC 61076-2-106, IP68, with threaded joint and vibration protection, empty housing for reception of crimp contacts, 360° shielded, optimized assembly

0314

Chassis plug acc. to IEC 61076-2-106, IP68, with threaded joint and solder terminals, for front mounting

0314-1

Chassis plug acc. to AISG specification and IEC 61076-2-106, IP68, with threaded joint and solder terminals, for front mounting

0315

Chassis plug acc. to IEC 61076-2-106, IP68, with threaded joint and solder terminals, for back side mounting

0315-1

Chassis plug acc. to AISG specification and IEC 61076-2-106, IP68, with threaded joint and solder terminals, for back side mounting

0316

Chassis plug acc. to IEC 61076-2-106, IP68, with threaded joint, for printed circuit boards, for front mounting

0316-1

Chassis plug acc. to AISG specification and IEC 61076-2-106, IP68, with threaded joint, for printed circuit boards, for front mounting

0317

Chassis plug acc. to IEC 61076-2-106, IP68, with threaded joint, for printed circuit boards, for back side mounting

0317-1

Chassis plug acc. to AISG specification and IEC 61076-2-106, IP68, with threaded joint, for printed circuit boards, for back side mounting

031798-1

Chassis plug acc. to IEC 61076-2-106 and AISG specification, IP68, with threaded joint and ground contact, for printed circuit boards, for back side mounting

0318

Flange chassis plug acc. to IEC 61076-2-106, IP68, with threaded joint and solder terminals, for front mounting

0318-1

Flange chassis plug acc. to AISG specification and IEC 61076-2-106, IP68, with threaded joint and solder terminals, for front mounting

0304

Chassis socket acc. to IEC 61076-2-106, IP68, with threaded joint and solder terminals, for front mounting

0304-1

Chassis socket acc. to AISG specification and IEC 61076-2-106, IP68, with threaded joint and solder terminals, for front mounting

0305

Chassis socket acc. to IEC 61076-2-106, IP68, with threaded joint and solder terminals, for back side mounting

0305-1

Chassis socket acc. to AISG specification and IEC 61076-2-106, IP68, with threaded joint and solder terminals, for back side mounting

0362

Chassis socket acc. to AISG specification and IEC 61076-2-106, IP68, with threaded joint, empty housing for reception of crimp contacts, for front mounting

0363

Chassis socket acc. to AISG specification and IEC 61076-2-106, IP68, with threaded joint, empty housing for reception of crimp contacts, for back side mounting

0306

Chassis socket acc. to IEC 61076-2-106, IP68, with threaded joint, for printed circuit boards, for front mounting

0306-1

Chassis socket acc. to AISG specification and IEC 61076-2-106, IP68, with threaded joint, for printed circuit boards, for front mounting

0307

Chassis socket acc. to IEC 61076-2-106, IP68, with threaded joint, for printed circuit boards, for back side mounting

0307-1

Chassis socket acc. to AISG specification and IEC 61076-2-106, IP68, with threaded joint, for printed circuit boards, for back side mounting

030798-1

Chassis socket acc. to IEC 61076-2-106 and AISG specification, IP68, with threaded joint and ground contact, for printed circuit boards, for back side mounting

0308

Flange chassis socket acc. to IEC 61076-2-106, IP68, with threaded joint and solder terminals, for front mounting

0308-1

Flange chassis socket acc. to IEC 61076-2-106 and AISG specification, IP68, with threaded joint and solder terminals, for front mounting

036297

Flange chassis socket acc. to AISG specification and IEC 61076-2-106, IP68, with threaded joint, empty housing for reception of crimp contacts, for front mounting

0369

Crimp contact, contact pin gold-plated

0364

Crimp contact, contact bush gold-plated

0314-2

SWUM™ chassis plug acc. to IEC 61076-2-106 and AISG specification, IP68/67, with threaded joint and solder terminals, for front mounting

0315-2

SWUM™ chassis plug acc. to IEC 61076-2-106 and AISG specification, IP68/67, with threaded joint and solder terminals, for back side mounting

0316-2

SWUM™ chassis plug acc. to IEC 61076-2-106 and AISG specification, IP68/67, with threaded joint, for printed circuit boards, manual soldering, for front mounting

0317-2

SWUM™ chassis plug acc. to IEC 61076-2-106 and AISG specification, IP68/67, with threaded joint, for printed circuit boards, manual soldering, for rear mounting

新

031799-2

SWUM™ chassis plug acc. to IEC 61076-2-106 and AISG specification, IP68/67, with threaded joint, for printed circuit boards, manual soldering, for back side mounting, with hexagonal nut

031798-2

SWUM™ chassis plug acc. to IEC 61076-2-106 and AISG specification, IP68/67, with threaded joint and ground contact, for printed circuit boards, manual soldering, for back side mounting

0318-2

SWUM™ flange chassis plug acc. to IEC 61076-2-106 and AISG specification, IP68/67, with threaded joint and solder terminals, for front mounting

0304-2

SWUM™ chassis socket acc. to IEC 61076-2-106 and AISG specification, IP68/67, with threaded joint and solder terminals, for front mounting

0305-2

SWUM™ chassis socket acc. to IEC 61076-2-106 and AISG specification, IP68/67, with threaded joint and solder terminals, for back side mounting

0306-2

SWUM™ chassis socket acc. to IEC 61076-2-106 and AISG specification, IP68/67, with threaded joint, for printed circuit boards, manual soldering, for front mounting

0307-2

SWUM™ chassis socket acc. to IEC 61076-2-106 and AISG specification, IP68/67, with threaded joint, for printed circuit boards, manual soldering, for back side mounting

030799-2

SWUM™ chassis socket acc. to IEC 61076-2-106 and AISG specification, IP68/67, with threaded joint, for printed circuit boards, manual soldering, for back side mounting, with hexagonal nut

030798-2

SWUM™ chassis socket acc. to IEC 61076-2-106 and AISG specification, IP68/67, with threaded joint and ground contact, for printed circuit boards, manual soldering, for back side mounting

0308-2

SWUM™ flange chassis socket acc. to IEC 61076-2-106 and AISG specification, IP68/67, with threaded joint and solder terminals, for front mounting

已淘汰

0315-1 U

Chassis plug acc. to IEC 61076-2-106 and AISG specification, IP68, with threaded joint, cables and potted solder area, for back side mounting

已淘汰

0305-1 U

Chassis socket acc. to IEC 61076-2-106 and AISG specification, IP68, with threaded joint, cables and potted solder area, for back side mounting

0383

Protecting cap, IP68, for plugs, with chain

038399

Protecting cap, IP68, for plugs, without chain

038899

Protecting cap, IP68, for plugs, without chain

0381

Protecting cap, IP68, for sockets, with chain

038199

Protecting cap, IP68, for sockets, without chain

038799

Protecting cap, IP68, for sockets, without chain

0382

Shielding or ground contact ring for chassis plugs and sockets with front mounting

0384

Hexagonal nut for chassis plugs and sockets (spare part)

0385

Slit nut for chassis plugs and sockets (spare part)

0308 C 02

Flat gasket for flange chassis plugs and sockets

0322 C 16

Flat gasket for sockets 030..., 032..., 036... (spare part)

0380

Wrench for plugs and sockets IP68

ZMS 20

Wrench for chassis connectors

Further products on request

Cable assemblies with connectors 0332-1 and 0322-1 acc. to AISG specification

Further products on request

Cable assemblies with connectors 0315-1 U and 0305-1 U acc. to AISG specification and RAST 2.5 direct connector 3517 (RAST 2.5, insulation displacement technology)
